Customized screw design, D45-120mm
L/D 30-40:1
Straight and spiral grooved water cooling feeding section
Large LCD control panel Self-developed operation program, BUS control
Option of DC or AC drive motor, real time power consumption indication
Efficient transmission and high torque gear box
Integrated gravimetric weight control as option
High precision melt temperature and pressure control
Model |
Screw D.(mm) |
L/D |
Max.Output HDPE (kg/h) |
Motor Power(kW) |
Drive Type |
EXT-SJ45-30 |
45 |
30:1 |
50/HDPE |
15 |
AC |
EXT-SJ60-33 |
60 |
33:1 |
350/HDPE |
75 |
AC |
EXT-SJ75-33 |
75 |
33:1 |
450/HDPE |
90 |
AC |
EXT-SJ90-33 |
90 |
33:1 |
700/HDPE |
160 |
AC |
EXT-SJ75-36 |
75 |
36:1 |
600/HDPE |
132 |
AC |
EXT-SJ90-36 |
90 |
36:1 |
900/HDPE |
200 |
AC |
EXT-SJ120-36 |
120 |
36:1 |
1300/HDPE |
355 |
AC |
EXT-SJ60-40 |
60 |
40:1 |
450/HDPE |
110 |
AC |
EXT-SJ75-40 |
75 |
40:1 |
850/HDPE |
200 |
AC |
