Hydraulic type
Heating plate coated with teflon
One or two side facing function
Temperature control, timer setting
Option of full automatic type
Model |
Working Range(mm) |
Heating Temperature Max.(℃) |
Heater Surface Temp. Tolerance(℃) |
Power Supply(V/Hz) |
Heating Power(KW) |
Facing Power(KW) |
Hydraulic Stantion Power(KW) |
Weight(kg) |
EXT-BF160 |
63-160 |
270 |
<±5 |
220,50 |
1.0 |
0.85 |
0.75 |
110 |
EXT-BF250 |
90-250 |
270 |
<±5 |
220,50 |
2.1 |
1.36 |
0.75 |
150 |
EXT-BF315 |
90-315 |
270 |
<±7 |
220,50 |
3.1 |
1.36 |
0.75 |
210 |
EXT-BF500 |
315-500 |
270 |
<±7 |
380,50 |
5.4 |
1.5 |
1.5 |
440 |
EXT-BF630 |
400-630 |
270 |
<±7 |
380,50 |
9.2 |
1.5 |
1.5 |
650 |
EXT-BF800 |
630-800 |
270 |
<±7 |
380,50 |
12.5 |
2.2 |
2.2 |
1260 |
